| MODEL |
RANGER 125 CBS |
| Engine |
Single cylinder, four Valve, water cooling, vertical |
| Displacement |
124.2cc |
| Bore × stroke mm |
58×47 |
| Maximum power |
14 Hp/8750rpm |
| Torque |
11Nm/8000rpm |
| Compression ratio |
12:1 |
| Variable speed |
6 |
| Maximum speed |
110km/h |
| Frame |
Steel pipe braided frame |
| Front wheel |
110/70 R17 M/C |
| Rear wheel |
150/70 R17 M/C |
| Front suspension |
positive absorber 120mm travel |
| Rear suspension |
single-middle 36mm travel |
| Front brake |
Single-disc Φ300mm, opposed four-piston caliper |
| Rear brake |
Single disc Φ240mm, single piston caliper |
| Brake system |
CBS |
| Length * Width * Height mm |
2070 * 818 * 1130 |
| Wheelbase mm |
1425 |
| Seat height mm |
810 |
| Ground clearance mm |
160 |
| Fuel tank volume L |
14,5 |
| Curb weight kg |
155 |
| Battery |
12V 7AH gel battery |
| Turn signal |
LED,flowing water light |
| Dashboaed |
TFT 5INCH,Blue tooth |
| Warranty |
2 Years or 20.000 km |
